Allis Chalmers 190XT Specs: Engine, Horsepower, Weight, and Review

Allis Chalmers 190XT specs sheet has information about the engine, horsepower, dimensions, weight, lift capacity, hydraulics, and tire size. You can also find an Allis Chalmers 190XT review at the end of the page, which can help you make a good purchase. Let’s get to the details of the 190XT Allis Chalmers tractor without further ado.

Allis Chalmers 190XT Specs

ManufacturerAllis Chalmers
Model190XT
TypeRow-crop
Price$8600
Years Model1964-1971
Allis chalmers 190xt

Serial Numbers

ModelBeginning Serial Number
19641001
19652485
19668219
196713273
196819262
196923234
197025901
197131118

Engine

Between the years it was manufactured, the Allis Chalmers 190XT tractor had three available engine(LP gas, Gasoline, and diesel) configurations. Due to the fact that these engines are distinct from one another, we have provided individual tables for each of them.

ManufacturerAllis Chalmers
ModelG2800XT (Gasoline), G2800LP (LP Gas), 2900XT (Diesel)
Type4-stroke liquid
Cylinders6
CombustionCarburetor
StarterElectric
Firing Order1-5-6-3-2-4
Compression Ratio8:1 (G2800XT), 9:1 (G2800LP XT), 16.25:1 (2900XT)
Rated Speed2200 RPM
ImperialMetric
Displacement301 in³4933 cc
Bore3.75 in.9.5 cm
Stroke4.25 in.10.8 cm
Fuel Tank Capacity14.5 gal54.5 L

Capacity

CapacityImperialMetric
Fuel Tank (gas/diesel)48 gal182 L
Fuel Tank LP52 gal197 L
Coolant Capacity18 gal68 L

Drivetrain

Transmission ModelAllis-Chalmers Power Director
Transmission TypePower shift
Gears8F/2R
Drive2WD
SteeringHydraulic
BrakesDisc

Travel Speed

Gearmphkmh
Max. Forward Speed13.621.9
Max. Reverse Speed3.95.3

PTO

PTO TypeLive
PTO Power94 HP (70 kW)
PTO RPM540 RPM

Hitch

CategoryCategory II 3-point hitch
Drawbar Power79 HP(59 kW)

Hydraulic

TypeOpen center
Pump Output12 GPM (45 L)
Rated Flow12 GPM (45 L)
Hydraulic Capacity9 gal (34 L)

Dimensions

ImperialMetric
Wheelbase105 in.266 cm

Tire Size

Front7.50-16
Rear18.4-34

Weight

TypeImperialMetric
Operating Weight11300 lbs5125 kg

Frequently Asked Questions About Allis Chalmers 190XT Tractor

How many horsepower was a 190XT?

190XT Allis Chalmers has 66 HP.

How much does an Allis Chalmers 190 weigh?

Allis Chalmers 190, weighs 11,300 pounds.

[taq_review]

You might also be interested in:Best Tractor Filters in 2026: Oil, Air & Fuel Guide for Maximum Performance
share Share facebook pinterest whatsapp x print

Related Posts

Allis Chalmers d17 specs
Allis Chalmers D17 Specs, Hydraulic System, Engine Oil Type, and Hydraulic Fluid
Mahindra 2638
Mahindra 2638 Specs, Value, Lift Capacity, and Review
massey ferguson 231 specs
