Between the years 1965 and 1975, the production of the Ford 3000 took place in Michigan (United States), Basildon (England), and Antwerp (Belgium). Two different engine options are available for the Ford 3000 tractor and four other transmission options. Variants of the 3000 series Ford tractors include the 3100 (all-purpose), 3300 (vineyard), and 3310 (narrow chassis) models, respectively. Keep reading if you want to get down to the nitty gritty of the Ford 3000 specs.
Ford 3000 Tractor Specs
| Manufacturer | Ford |
| Model | 3000 |
| Type | Utility tractor |
| Years Model | 1965-1975 |
Engine
| Engine Manufacturer | Ford |
| No of Cylinder | 3 |
| Type | Gasoline or Diesel |
| Fuel injection Pump | In-line |
| Timing | 19° |
| Coolant System | Pressurized liquid recirculating by-pass |
| Temperature Control | Thermostat |
| Compression Ratio | 8:1 (Gasoline) 16.5:1 (Diesel) |
| Firing Order | 1-2-3 |
| Max. Working Speed | 2100 RPM 2000 RPM |
| Horsepower | 47 HP (gas) 35 kW 44 HP (diesel) 33 kW |
| Displacement | 158 cub. in. (gas) 2589 cc 175 ins. (diesel) 2868 cc |
| Bore and Stroke | 4.2×3.8 in. (gas) 107×98 mm 4.2×4.2 in. (diesel) 107×107 mm |
Fluid Capacities
| Capacity | Us | Imperial |
|---|---|---|
| Fuel Tank | 13 gal | 49 L |
| Coolant | 3.4 gal | 13 L |
| Engine Oil | 2 qts | 1.9 L |
Engine Oils
| BELOW 10°F | 10°F-40°F | 32°F-90°F | ABOVE 75°F | |
|---|---|---|---|---|
| Ford Oil Specs | M2C87-A5W | M2C87-A10 | M2C87-A20 | M2C87-A30 |
| Viscosity | SAE 5W, SAE 5W/20 | SAE 10W | SAE 20W | SAE 30W |
| Oil Change Period | 150 hours | 300 hours | 300 hours | 300 hours |
Transmissions
The Ford 3000 tractor comes with four different unsynchronized transmission options.
| Type | 10-speed / 2 reverse (full power shift) 12-speed / 3 reverse 8-speed / 2 reverse 6-speed / 2 reverse |
| Clutch | Single dry disc |
| Transmission Oil Capacity | 3.3 gal 12.5 L |
| 10 Speed | 12 Speed | 8 Speed | 6 Speed | |
|---|---|---|---|---|
| Max. Forward Speed | 16 mph 26 kmh | 22 mph 36 kmh | 17 mph 28 kmh | 18 mph 29 kmh |
| Max. Reverse Speed | 5 mph 7 kmh | 6 mph 10 kmh | 8 mph 13 kmh | 7 mph 12 kmh |
Power Take-Off (PTO)
| PTO | Live |
| Type | Single dry Plate |
| PTO Speed | 1600-1800 RPM |
| PTO Horsepower | 41 HP 30 kW |
Power Take-Off (PTO)
| Type | Piston type |
| Pump Flow | 4 GPM 15 LPM |
| Pressure | 2500 psi |
| Hydraulic Capacity | 6 gal 24 L |
Dimensions
| Dimension | Vineyard | Narrow |
|---|---|---|
| Height to Hood Line | 54 in. | 53 in. |
| Ground Clearance | 21 in. | 21.5 in. |
| Wheelbase | 80 in. | 77 in. |
| O/A Width | 63 in. | 72.5 in. |
| Turning Radius | 153 in. | 129 in. |
Tire Size
| Front | 5.50-16 6.00-16 |
| Rear | 12.4-28 14.9-24 16.9-24 13.6-28 |
Weight
| Weight | Imperial | Metric |
|---|---|---|
| Operating Weight | 3700 lbs | 1680 kg |
Frequently Asked Questions About 3000 Ford Tractor
The Ford 3000 tractor has 41 horsepower.
The Ford 3000 tractor was produced from 1965 to 1975.
Ford 3000 tractor weighs 3,700 pounds.
The Ford 3000 has a 13-gallon fuel capacity.
The Ford 3000 tractor oil capacity is 2.0 qts.
For the Ford 3000 engine, SAE 5W/20, SAE 10W, SAE 20W and SAE 30W engine oil are suitable.
The Ford 3000 tractor, which has been in production since 1965, is a powerful and dependable workhorse. It is a popular tractor among small farms and hobby farmers. The Ford 3000 tractor is well-known for its toughness, dependability, and versatility. It can be used for a variety of tasks including tilling, mowing, and hauling.Ford 3000 Tractor Review
