Massey Ferguson 231 Specs, Horsepower, Capacity, and Review
Massey Ferguson 231 is a well-known farming tractor used by farmers and agricultural workers all over the world. 231 Massey Ferguson has been in production since the early 1990s and has grown in popularity over time. It is well-known for its dependability, durability, and adaptability. We will go over the MF 231 specs, horsepower, capacity, and review so you can get a sense of what this tractor can do for you.
Massey Ferguson 231 Specs
| Manufacturer | Massey Ferguson |
| Model | 231 |
| Series | 200 One Series |
| Type | Utility tractor |
| Years Model | 1989-1999 |
Engine
| Manufacturer | Perkins |
| Model | AD3.152 |
| Type | Diesel 4-stroke liquid |
| Cylinders | 3 |
| Combustion | Direct injection |
| Cylinder Sleeves | Dry |
| Starter | Delco-Remy 1107870 |
| Compression Ratio | 18.5:1 |
| Firing Order | 1-2-3 |
| Rated Speed | 2400 RPM |
| Imperial | Metric | |
|---|---|---|
| Horsepower | 37.4 HP | 27.9 kW |
| Displacement | 152 in³ | 2491 cc |
| Bore | 3.6 in. | 9.1 cm |
| Stroke | 5.0 in. | 12.7 cm |
Capacity
| Imperial | Metric | |
|---|---|---|
| Fuel Tank | 14 gal | 53 L |
| Cooling System | 11 qts | 10.5 L |
Driveline
| Chassis | 4×2 2WD |
| Steering | Power assist |
| Brakes | Drum |
| Cab | Two-post folding ROPS and Canopy(optional) |
Transmission
| Transmission Type | Sliding gear |
| Gear Selections | 6 forward 2 reverse |
| Clutch | Dry disc |
Travel Speed
| Imperial | Metric | |
|---|---|---|
| Max. Forward | 14.3 mph | 23.1 kW |
PTO
| Type | Live |
| PTO Speed | 540 RPM |
| PTO Power | 34 HP (25 kW) |
Hitch
| Category | II/I |
| Control | Position and draft control |
Hydraulic
| Type | Open |
| Hydraulic Capacity | 9.2 gal 34.8 L |
Loader Specifications
| Model No | Massey Ferguson 232 Loader |
| Imperial | Metric | |
|---|---|---|
| Width | 60 in. 72 in. | 152 cm 182 cm |
| Maximum Lift Height | 106 in. | 269 cm |
| Dump Clearance | 80 in. | 203 cm |
| Reach at Maximum Height | 63 in. | 161 cm |
| Lift Breakout Force | 2600 lbs | 1179 kg |
| Lift to Full Height Pin | 2600 lbs | 816 kg |
Dimensions
| Imperial | Metric | |
|---|---|---|
| Length | 128 in. | 325 cm |
| Width | 76 in. | 193 cm |
| Height | 88 in. | 222 cm |
| Wheelbase | 76 in. | 193 cm |
| Ground Clearance | 13 in. | 32.5 cm |
Tire Size
| Tire | Size |
|---|---|
| Front | 6.00-16 |
| Rear | 13.6-28 |
Weight
| Imperial | Metric | |
|---|---|---|
| Operating Weight | 4050 lbs | 1837 kg |
Frequently Asked Questions About 231 Massey Ferguson Tractor
What HP is a Massey Ferguson 231?
The Massey Ferguson 231 has 37 horsepower.
What years did make the 231?
The 231 Massey Ferguson was manufactured from 1989 until 1999.
How much does a Massey 231 weigh?
The Massey 231 weighs 4,050 pounds.
How wide is a Massey Ferguson 231?
Massey Ferguson 231 wide is 76 inches.
